Middle Sealing Three Side Sealing Bag Making Press

FOB Reference Price:Get Latest Price
$30,000.00 - $45,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Machine Type:
Bag Forming Machine
Bag Type:
Zipper Bag
Condition:
New
Material:
Plastic
Computerized:
Yes
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
WEIBANG
Model Number:
WBAY-FB
Voltage:
220V
Power(W):
40kw
Dimension(L*W*H):
9000*1900*1870
Weight:
4.5T
Certification:
CE ISO9001
Computerized::
yes
function::
three side sealing, zipper bag , standing bag
Material::
Plastic,Paper
Machine Type::
Bag Forming Machine
Bag Type::
Middle sealing bags,For Food,Industry
After-sales Service Provided::
Engineers available to service machinery
Automatic Grade:
Automatic
Type:
Bag Making Machine
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1year
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Film packing,the wooden box.
Port
Ningbo
Lead Time :
30days





Application:

With such characteristics as reasonable structure,easy operation and high automatic,this machine is sutibale for producing three side sealing pouch from various plastic-plastic,paper-plastic,paper-paper laminated material.



Feature:

1. Whole machine controlled by imported central PLC control system with man-machine interface. More stable performance, easy for operation and maintenance. Chinese and English interface language can be shifted easily.
2.Constant auto-tension control for unwinding,LPC edge alignment,AC inverter constant speed auto material feeding.

3. Imported double servo-motor material dragging control system.

4.Main motor for up-down sealing and pressing equipped with inverter.
5. PID for sealing bar temperature adjustment,no touch auto control,centralized setting in man-machine interface.
6. Equipped with pneumatic multi-function auto punching device ,trim cutting and auto rewinding and static eliminator.

7. Temperature adjustment range:0~300 °C

8. Counter:quantity,batch accumulation,pre-set available.

9. Operation Method:by length fixation control and /or by photocell tracking control.
10. Punching device:working rhythm can pre-set as continuous,interval or stop,punching time can be pre-set.
11. Material skip feeding:one to six times available.

12.Batch conveying function avaiable ,the quantity of batch can be preset.



Main Technical Parameters:

Bag Type

 Three Side Sealing Bag

Model

400mm  500mm  600mm

Cutting speed

150times/min

Power

40kw

Weight

4500kg

Machine size

10500 ×1850 ×1870mm
